Security Policy, Version 1.3
December 21, 2015
McAfee Web Gateway WG5000 and WG5500 Appliances
Page 7 of 35
© 2015 McAfee, Inc.
This document may be freely reproduced and distributed whole and intact including this copyright notice.
Figure 2 Typical Deployment Scenario
Table 1 below provides general specification for the McAfee Web Gateway WG5000 and WG5500
Appliances.
Table 1 McAfee Web Gateway Model Specifications
WG5000
WG5500
Form Factor
1U rack-mount
2U rack-mount
Processor
Intel Xeon E5640
(quad core)
Intel Xeon E5660
(2 quad core)
Memory
6 GB
12 GB
Interfaces
4 x 10/100/1000
4 x 10/100/1000
RAID14
RAID 0/1/10
RAID 0/1/10
Hard Disk
Available: 6 x 300 GB SAS
Installed : 2 x 300 GB SAS
Available: 8 x 300 GB SAS
Installed : 6 x 300 GB SAS
Power Supply
Redundant
Redundant
The McAfee Web Gateway WG5000 and WG5500 Appliances are validated at the FIPS 140-2 Section
Table 2 Security Level Per FIPS 140-2 Section
Section
Section Title
Level
1
Cryptographic Module Specification
2
2
Cryptographic Module Ports and Interfaces
2
3
Roles, Services, and Authentication
2
4
Finite State Model
2
5
Physical Security
2
6
Operational Environment
2
7
Cryptographic Key Management
2
8
EMI/EMC15
2
14 RAID Redundant Array of Inexpensive Disks
