Security Policy, Version 0.10
February 27, 2015
HP P-Class Smart Array RAID Controllers
Page 18 of 27
© 2015 Hewlett-Packard Development Company, L.P.
This document may be freely reproduced and distributed whole and intact including this copyright notice.
Metal Cover (1)
Tape (1)
Tape (3)
Tape (2)
Tape (3)
Tape (1)
Tape (2)
Figure 2 P230i Controller
b.
The P430 and P431 are stand-up cards and are shown in Figure 3 and Figure 4 with the
physical security kit installed. The P430 is shown with the required one (1) metal cover
and one (1) section of tamper-evident tape. The P431 is shown with the required one (1)
metal cover and one (1) section of tamper-evident tape.
Metal Cover (1)
Metal
Cover
(1)
Tape
(1)
Figure 3 P430 Controller
