5. ROLES & SERVICES
5.1 ROLES
The Cyberflex Access E-gate V3 cryptographic module defines two distinct roles that are supported by the internal
cryptographic system: the Cryptographic Officer and the User/Applet Provider.
·
Cryptographic Officer: This role is the internal security controller. The Cryptographic Officer establishes his
identity on the module by demonstrating to the Card Manager application that he possesses the knowledge of a
TDES key set stored within the Card Manager. By successfully executing a series of commands, the Cryptographic
Officer establishes a secure channel to the Card Manager. The establishment of this channel includes mutual
authentication of identities between the Cryptographic Officer and the Card Manager. Once a secure channel is
established, the Card Manager grants authorization (on the module) to information and services. The Card
Manager Security Domain corresponds to Card Issuer Security Domain.
·
User/Applet Provider: The Applet Provider is the applet developer that uses Java API, provided by the module.
Cryptographic services provided by the Cyberflex Access E-gate V3 cryptographic module are delivered through
the use of appropriate APIs. An applet has its own Security Domain (Applet Provider Security Domain).
Identity based Authentication
·
Identification. The operator identifies himself by selecting the application appropriate for his role and the key set
inside the application. The application of Cryptographic Officer is the Card Manager. The application of the
User/Applet Provider is his own applet. Selection of the application is done by a SELECT command. Selection of
the key set is done in the INITIALIZE UPDATE command, the first command of the two commands to open a
Secure Channel.
·
Authentication. The operator authenticates himself using a mutual authentication comprising two commands,
INITIALIZE UPDATE and EXTERNAL AUTHENTICATION. During this mutual authentication, the operator has to
encrypt a message sent by the card, proving knowledge of the TDES key set, which was referenced during the
identification.
Notes:
1.
The Cardholder is the end user of the Cyberflex Access E-gate V3 cryptographic module (when applets are
loaded), who is in charge of insuring the ownership of his Cyberflex Access E-gate V3 cryptographic module...
2.
Applets that will be downloaded onto the Cyberflex Access E-gate V3 cryptographic module may define other
distinct roles that will be part of the applet's validation.
The Card Manager is the controlling application on the Cyberflex Access E-gate V3 cryptographic module. It is invoked
following every Cyberflex Access E-gate V3 cryptographic module reset and initialization operation.
