Card OS
Java Card Virtual Machine
Card
Manager
And
Security
Domains
I/O
Cryptographic
Services
Memory Mgmt
services
Reset
Power
Chip
I/O
Services
SSO
applet
Java
Card
API
Open
Platform
API
PIV
applet
Java
Card
API
Open
Platform
API
PIV Instance
With
NIST AID
Contains
All
FIPS 201
Data Objects
Mandatory
And
Optional
Other
Instances
of PIV applet
(optional)
Used for
Additional
containers
proprietary to
each agency
Binary Files
(optional)
Data Storage
for additional
applications like
contactless
access log
and
DESFIRE/HID
"emulation"
Figure 3: Functional block diagram
4.1
Module Identification
This document addresses the submission for validation of the module Oberthur PIV EP v1 on ID-One
Cosmo 64 v5 D based on the following configuration:
·
Hardware Platform # `77' with Firmware `E303-063684' and PIV EP v1 Applet Suite.
Oberthur PIV EP v1 Applet Suite is made up of the following two applets:
o
PIV Applet Version 1.08
o
SSO Applet Version 1.08
For the purpose of this validation the Oberthur PIV EP card should be viewed as a whole and indivisible
entity. Although it is technically based on the ID-One Cosmo 64 v5 Java Card platform, the system software
of the said platform requires a special customization to support the Oberthur PIV firmware application.
When delivered to the customer the module is already in FIPS mode with the PIV EP Applet Suite loaded
and instantiated.
The hardware module complete Identification and configuration can be retrieved at any time using the Get
Data services described in paragraph 6.4.1 and in the product user guide.
