Secure Operation of the Cisco 2691, 3725, and 3745 Routers

The Cisco 2691 and 3725 Modular Access Routers with AIM-VPN/EP II and the Cisco 3745 Modular

Access Router with AIM-VPN/HP II meet all the Level 2 requirements for FIPS 140-2. Follow the

setting instructions provided below to place the modules in FIPS mode. Operating the routers without

maintaining the following settings will remove the modules from the FIPS approved mode of operation.

Initial Setup

The Crypto Officer must ensure that the AIM-VPN/EP II or AIM-VPN/HP II cryptographic

accelerator card is installed in the module by opening the chassis and visually confirming the

presence of the AIM-VPN/EP II or AIM-VPN/HP II.

The Crypto Officer must apply tamper evidence labels as described in the "Physical Security"

section of this document.

Only a Crypto Officer may add and remove Network Modules. When removing the tamper evidence

label, the Crypto Officer should remove the entire label from the router and clean the cover of any

grease, dirt, or oil with an alcohol-based cleaning pad. The Crypto Officer must re-apply tamper

evidence labels on the router as described in the "Physical Security" section of this document.

Only a Crypto Officer may add and remove WAN Interface Cards. When removing the tamper

evidence label, the Crypto Officer should remove the entire label from the router and clean the cover

of any grease, dirt, or oil with an alcohol-based cleaning pad. The Crypto Officer must re-apply

tamper evidence labels on the router as described in the "Physical Security" section of this

document.

The Crypto Officer must disable IOS Password Recovery by executing the following commands:

configure terminal

no service password-recovery

end

show version

Note

Once Password Recovery is disabled, administrative access to the module without the

password will not be possible.

System Initialization and Configuration

The Crypto Officer must perform the initial configuration. IOS version 12.3(3d) is the only

allowable image; no other image may be loaded.

The value of the boot field must be 0x0101 (the factory default). This setting disables break from

the console to the ROM monitor and automatically boots the IOS image. From the "configure

terminal" command line, the Crypto Officer enters the following syntax:

config-register 0x0101

The Crypto Officer must create the "enable" password for the Crypto Officer role. The password

must be at least 8 characters and is entered when the Crypto Officer first engages the "enable"

command. The Crypto Officer enters the following syntax at the "#" prompt:

enable secret [

PASSWORD]
