FIPS 140-2 Non-Proprietary Security Policy, Version 0.8
March 17, 2016
Sonus SBC 7000 Session Border Controller
©2016 Sonus Networks, Inc.
This document may be freely reproduced and distributed whole and intact including this copyright notice.
Page 14 of 32
X Execute: The CSP is used within an Approved or Allowed security function or authentication
mechanism.
Table 5 Authorized Operator Services
Service
Operator
Description
Input
Output
CSP and Type of Access
CO
User
Commission the
module
Commission the module
by following the Security
Policy guidelines
None
None
None
Manage SBC
License
Installs the license to
enable SBC features;
delete or update license;
view current license
status
Command
Status output
None
Configure the SBC
system
Define network interfaces
and settings; set
protocols; configure
authentication
information; define
policies and profiles
Command
and
parameter
Command
response/
Status output
None
Configure routing
policy and control
services
Configure IP network
parameters and profiles
for signaling, media, call
routing, call services,
zone, IP ACL49 rules, NTP50
and DNS51 servers
Command
and
parameters
Command
response/
Status output
None
Configure Crypto
Suite Profile
Select crypto suites for
SRTP, SRTCP, and SIP
communication
Command
and
parameters
Command
response/
Status output
None
Configure Call Data
Record (CDR)
Configure log file behavior
Command
and
parameters
Command
response/
Status output
None
Manage users
Create, edit and delete
users; define user
accounts and assign
permissions.
Command
and
parameters
Command
response/
Status output
Password R/W/X
Manage user
sessions
Terminate User sessions
Command
and
parameters
Command
response/
Status output
TLS Session Key W
49 ACL Access Control List
50 NTP Network Time Protocol
51 DNS Domain Name System
