Each backbone model supports a selected set of blades:
B ackbone Model
Blades (ma x count)
DCX (12 slots) 1
CP8 (2), CR8 (2), FC8-16 (8), FC8-32 (8), FC8-48 (8), FC8-64 (8), FX8-24 (1),
DCX/DCX 8510-8 Filler Panel (10)
DCX 8510-8 (12 slots) 1
CP8 (2) 1, CR16-8 (2), FC8-64 (8), FC16-32 (8), FC16-48 (8), FX8-24 (1),
DCX/DCX 8510-8 Filler Panel (10)
DCX-4S (8 slots) 1
CP8 (2) , CR4S-8 (2), FC8-16 (4), FC8-32 (4), FC8-48 (4), FC8-64 (4), FX8-24(1),
DCX-4S Backbone Filler Panel (6), DCX-4S/DCX 8510-4 Filler Panel (6)
DCX 8510-4 (8 slots) 1
CP8 (2) , CR16-4 (2), FC8-64 (4), FC16-32 (4), FC16-48 (4), FX8-24 (1),
DCX-4S/DCX 8510-4 Filler Panel (6)
Table 5 - Backbone Blade Support Matrix
Table 5 Notes
1.
Each Backbone Model shall be fully populated with a minimum of two CP8 Control Processor Blades
(Part Number: 80-1001070-06 or 80-1006794-01).
The name of a backbone-based validated module configuration is formed by a concatenation of part
numbers of the specific set of blades installed in the backbone.
For the DCX and DCX 8510-8 platforms:
<Backbone PN><Slot 1 PN><Slot 2 PN>....<Slot 12 PN> For the DCX-4S and DCX 8510-4 platforms:
<Backbone PN><Slot 1 PN><Slot 2 PN>....<Slot 8 PN>
