BrocadeŽ FCX 624/648, ICXTM 6610, ICX 6450, ICX 6650 and SX 800/1600 Series Non-Proprietary Security Policy
Version 1.0
Brocade Communications Systems, Inc.
Page 9 of 55
6
ICX 6450 Series
Table 6 ICX 6450 Switch Family Part Numbers of Validated Cryptographic Modules
SKU
MFG Part Number
BriefDescription
ICX 6450-24
80-1005997-03
24-port 1G Switch, 2x1G SFP+ (upgradable to 10G) &
2x1G/10G SFP+ Uplink/Stacking Ports
ICX 6450-24P
80-1005996-04
24-port 1G Switch PoE+ 390W, 2x1G SFP+ (upgradable
to 10G) & 2x1G/10G SFP+ Uplink/Stacking Ports
ICX 6450-48
80-1005999-04
48-port 1G Switch, 2x1G SFP+ (upgradable to 10G) &
2x1G/10G SFP+ Uplink/Stacking Ports
ICX 6450-48P
80-1005998-04
48-port 1G Switch PoE+ 780W, 2x1G SFP+ (upgradable
to 10G) & 2x1G/10G SFP+ Uplink/Stacking Ports
ICX6450-C12-PD
80-1007578-01
12-port 1G Compact Switch (4 PoE+), 2X100M/1G SFP,
2X100M/1G Copper Uplinks, Fanless, Layer 3
XBR-000195
N/A
FIPS Kit containing tamper evident labels to be affixed
to the module per Appendix A: Tamper Label Application
in this document. All SKUs listed above utilize this kit to
satisfy the physical security requirements
Figure 9 illustrates the ICX 6450-24 and ICX 6450-24P cryptographic module (See Table 5 ICX 6610 Switch
Family Part Numbers)
Figure 9 ICX 6450-24 and ICX 6450-24P cryptographic modules
Figure 10 illustrates the ICX 6450-48 and ICX 6450-48P cryptographic modules (See Table 5 ICX 6610 Switch
Family Part Numbers).
Figure 10 ICX 6450-48 and ICX 6450-48P cryptographic modules
Figure 11 ICX 6450-C12-PD cryptographic modules
