BrocadeŽ FCX 624/648, ICXTM 6610, ICX 6450, ICX 6650 and SX 800/1600 Series Non-Proprietary Security Policy
Version 1.0
Brocade Communications Systems, Inc.
Page 16 of 55
Table 18 ICX 6450 Port mapping to logical interface
Physical Port
Logical Interface
SFP/SFP+ ports
Data input/Data output, Status output
10/100/1000 Mbps RJ-45 ports
Data input/Data output, Status output
AC socket
Power
External power supply connector (EPS)
(The ICX 6450-24, ICX 6450-24P and ICX 6450-48
have one EPS connector. The ICX 6450-48P has two
EPS connectors)
Power
Out of band management port
Control input, Status output
Console Port
Control input, Status output
Reset
Control input
LED
Status output
Table 19 ICX 6450 Series Physical Port LED Status
LED
Condition
Status
Ethernet Ports
24-port and 48-port models
On/FlashingGreen
The port has established a valid link at 10, 100
or 1000 Mbps. Flashing indicates the port is
transmitting and receiving user packets.
Off
A link is not established with a remote port.
PoE/PoE+
24-port and 48-port models
On/Green
The port is providing PoE or PoE+ power to a
connected device.
Off
The port is not providing PoE or PoE+ power.
SFP/SFP+
(X1 - X4) for ICX 6450 devices
On/FlashingGreen
The SFP port is operating at 10 Gbps. Flashing
indicates the port is transmitting and receiving
user packets at 10 Gbps.
On/FlashingYellow
The SFP port is operating at 1 Gbps. Flashing
indicates the port is transmitting and receiving
user packets at 1 Gbps.
Off
A link is not established with a remote port.
Out-of-band management port (2
LEDs)
Off (both LEDs)
Offline.
On/Flashing(left
side)
Link-up. Flashing indicates the port is
transmitting and receiving user packets.
On/Green (right
side)
1 Gbps Link-up.
Right LED off, left
LED on or flashing
10/100 Mbps Link-up. Flashing indicates the
port is transmitting and receiving user packets.
Table 20 ICX 6450 System LED Status
LED
Condition
Status
EPS1 and EPS2
(External Power Supply status for
ICX 6450-48P devices only)
Green
EPS1 and EPS2 power supplies are operating
normally.
Yellow
EPS1 and EPS2 power supply fault.
